S225-10-10
1-6
TABLE 1-2
CL-5 Series Control Programming Checklist
Step Activity/Question
Function Factory Owner
Check
Next
Code Set Set Step
A Power up control or run Self Test (FC 91).
Pass = B; Fail = Refer to page 2-5
B Access Security Level 3.
99 32123 C
Set Voltage 1 120
Bandwidth 2 2
C Set the Forward Power Flow Control Settings -- Time Delay 3 30
LDC Resistance 4 0
LDC Reactance 5 0 D
D Verify position indicator is in sync with tap changer by stepping
through the neutral position. E
E Is the Control Tap Position in sync with the position indicator? 12P No = F; Yes = G
F Set the Control Tap Position. 12P G
G Is Source Side Voltage Calculation required? 39 0 No = J; Yes = H
H Activate Source Side Calculation. 39 1 I
I Set Type of Regulator. (A and Series Transformer =1; B=2) 39-1 Nameplate value J
J Change Control I.D.? 40 Control Serial No. No = L; Yes = K
K Set Control I.D. 40 L
L Is regulator bank configuration closed or open delta? No = O; Yes = M
M Refer to Determination of Leading or Lagging, page 1-7. N
N Set Regulator Configuration. 41 0 O
O Change Operating Mode? (Factory set for sequential) 42 0 No = Q; Yes = P
P Set Operating Mode. 42 Q
Q Set System Line Voltage. 43 Rated Voltage R
R Set Overall P.T. Ratio. (from Nameplate) 44 Rated P.T.Ratio S
S Verify C.T. Primary Rating. (from Nameplate) 45 Rated C.T. Primary T
T Change Demand Time Interval?
46 15 No = V; Yes = U
U
Set Demand Time Interval. 46 V
V Change Tap Changer selection? 49 Nameplate value No = X; Yes = W
W Set Tap Changer selection. 49 Nameplate value X
X Are date and time correct?
50 No = Y; Yes = Z
Year 50-1
Month 50-2
Y Set the required date and time by way of subfunctions- Day 50-3
Hour 50-4
Minute 50-5
Second 50-6 Z
Z Should control be set up to react to a reverse power flow condition? No = AA; Yes = BA (Table 1-3)
AA Verify Reverse Sensing Mode is set on Locked Forward (0). 56 0 AB
AB Verify the baud rate of Local Channel #1 (Data Reader) is set for 4800. 60 4 AC
AC Set up Remote Communications Channel #2? No = AE; Yes = AD
64
65
AD Set Remote Communications Function Codes as desired. 66
67
68-1
68-2 AE
AE Verify the Blocking Status is normal. 69 0 AF
AF Is Voltage Reduction required? 70 0 No = AH; Yes = AG
70
72
AG Set Voltage Reduction Function Codes as desired. 73
74
75
76
77 AH
AH Is Soft Add-Amp required? 79* 0 No = AJ; Yes = AI
AI Activate Soft Add-Amp. 79* 1
Set Add-Amp Raise Limit. 79-1*
Set Add-Amp Lower Limit. 79-2* AJ
AJ Is Voltage Limiter required? 80 0 No = AL; Yes = AK
80
AK Set Voltage Limiter Function Codes as desired.
81
82 AL
85*
85-1
AL Set Profile Recorder Parameters. 85-2
85-3
85-4
85-5* AM
AM Is Security Override required? 92 0 No = AO; Yes = AN
AN Set Security Override. 92 1 AO
AO Change Security Codes? No = AQ; Yes = AP
96 1234
AP Set Security Codes as desired. 97 12121
98 32123 AQ
AQ Reset Metering & Tap Position. 38 AR
AR Take Data Reader reading (optional). AS
AS Press DISPLAY OFF key to return to Base Security Level.
AT
AT CONTROL IS NOW FULLY PROGRAMMED.
