Schematic Diagram of The Control Panel
Figure (7)
Instructions For Use
OR
OR
Timer Regulating key
Preparation Before Using:
After power on, the buzzer beep once, all the indicators light up for 1 second and
then go out, which indicates the induction hotplate enters the state of standby.
Put the pot in the center of the heating zone.
Operation Instructions:
When the “ON / OFF” button is pressed, all the indicators show "-" .
According to the heating zone where the pot is placed, press the "+" or "-"
button, select a relevant zone ,the indicator displays 5, then adjust the power
levels using the "+" or "-" button.
AND
Or press the "+" and "-" buttons simultaneously, the power setting immediately
chang to 0, and all the cooking zone switch off.
Boost
On/OFF
Power Regulating key
Lock
14
