SECTION 03
GLASS DOOR
1. Unplug the appliance and empty the contents,
including the shelves.
2. Carefully place the minibar on its back so the
door is facing up.
3. Remove the cap covering the top hinge. Using a
screw driver, remove the screws and hinge, then
remove the door.
4. Locate the second hinge on the bottom of the
minibar and remove the screws & hinge with a
screw driver.
5. Remove the blanking plate covering the screw
holes on the top of the minibar. Put the top hinge
in to place and attach with the screws (re-install
the blanking plate over the previous top hinge
position).
6. Remove the screws at the new bottom hinge position
and screw them in to the revealed holes at the
previous bottom hinge position.
7. Put the door in place ensuring it is the correct way
up and screw the bottom hinge in place.
8. Test the door to make sure both hinge brackets are
tight and secure before use.
BOTTOM
