07
SECTION 03
INSTALLATION
Positioning
Do not position this product in a location where it may be subject to extreme
temperatures, where it could be exposed to direct sunlight, or next to a heat
source.
The unit should be located in a cool, dry place.
Allow sufficient clearance around the minibar and ensure that it is positioned on a
stable and level surface.
Fixing the minibar - Eton-E Only
1. Position the fixing bracket at least 75mm away from the
wall/surface and screw it into place using 2 x screws.
Note: The bracket sits 215mm from the FRONT
of the minibar door. Please take this into consideration
when positioning the minibar and bracket.
IMPORTANT:
The bracket must be positioned centrally to
minibar in order to secure the minibar.
It is vital that a 50mm gap is left between the minibar’s sides, rear and top and any
surrounding surfaces (A)
AA
Front View
A
A
Side View
215mm
>75mm
>75mm
TOP VIEW
