08
SECTION 03
2. Lift the minibar into place and slide backwards until
the rear feet sit underneath the fixing bracket.
3. Open the minibar door to reveal the front feet.
4. Screw the minibar into place using 2 x screws and
the 2 x holes in the front feet.
Changing the door
Ensure the minibar is placed on an even, flat surface when
changing the door
Please follow the relevant instructions
SOLID DOOR
1
2
3
4
RETRO 40L MINIBAR
To change the orientation of the
door, follow the steps for the Solid
Door Minibar but refer to the
adjacent image for parts
identification.
1. Door 2. Top Hinge 3. Screws 4. Screw Caps
