09
SECTION 03
1. Unplug the appliance and empty the contents,
including the shelves.
2. Carefully place the minibar on its back so the
door is facing up.
3. Remove the cap covering the top hinge.
4. Locate the second hinge on the bottom of the
minibar and remove the screws & hinge with a
screw driver.
5. Unhook the door from the top hinge. Then, using a screw
driver, remove top hinge.
6. Remove the caps covering the screw holes in the top
corner of the minibar. Put the top ‘left’ hinge
(provided separately to the product) in to place and
attach with the screws (re-install the caps over the
previous top hinge position).
7. Remove the screws at the new bottom hinge position
and screw them in to the revealed holes at the
previous bottom hinge position.
8. Put the door in place ensuring it is the correct way
up and screw the bottom hinge in place.
9. Test the door to make sure both hinge brackets are
tight and secure before use.
BOTTOM
