Core RC PACE-45R User Manual

Programmable items and default settings
Default settings are shown in the grey boxes
programmable
Items
Programmable Value
1
2
3
4
5
6
7
8
9
Cut-off Voltage
2.6V/cell
2.8V/cell
3.0V/cell
3.2V/cell
3.4V/cell
No
cut-off
Running Mode
Forward
w/o
Reverse
Forward
with pause
then
Reverse
Forward/
Reverse
Motor timing
„Blinky‟
Low
Normal
High
Very High
Initial
Acceleration
Low
Medium
High
Very High
Throttle Percent
Reverse
20%
30%
40%
50%
60%
70%
80%
90%
100%
Throttle Limit
0%
20%
30%
40%
50%
60%
70%
80%
90%
Percentage
Braking
10%
20%
30%
40%
50%
60%
70%
80%
100%
Percentage Drag
Brake
0%
4%
8%
12%
15%
20%
25%
30%
Motor Rotation
Normal
Reverse
Neutral Range
2%
3%
4%
5%
6%
10%
Sensored/Sensorless brushless PACE-45R general information
1. Cutoff Voltage
 Automatically detect the number of the cells
According to the type of your batteries, set up the type of the batteries and Low Voltage Cutoff
Threshold via PC software or program card. The PACE-45R can detect the Voltage of the battery anytime
and will stop working once the Voltage of the battery is lower than the preset Low Voltage Cutoff
Threshold.
 Customized Voltage Cutoff (for NiMH or NiCd Batteries) you can select a starting cutoff voltage of
4, 5, or 6 volts. Then using the up/down to the right of the voltage you can increase the voltage
stepping up 0.1V between the selectable settings.
* When using any Lithium or M1 (A123) batteries, they must not be discharged to less than 3.0V
per cell.
2. Running Mode
Forward w/o Reverse
Reverse is disabled.
Forward with pause then Reverse: (DEFAULT)
The PACE-45R requires 1 second of continuous neutral from the transmitter prior to allowing reverse to
operate.
Note: There is automatic protection within the PACE-45R. Only after you have stopped and
