Core CLT1564 - Unit at a Glance; Hardware Component Identification

3
Unit at a Glance
1. Power Button: Turn your device on or o. Use to set your device to
Sleep or to wake it from Sleep.
2. Front Camera: Take photos and videos.
3. Touchpad: Use the touchpad to move your cursor.
2
5 6 6 1
4
3
9
10
11
12
LEFT RIGHT
FRONT TOP
BOTTOM
FCC ID: 2AVRVCLT1564 NS MODEL: CLT1564SL
CORE INNOVATIONS 12VDC/2A CHARGER
USB
USB
7
8
14 13
