EM 8070 operator’s manual
INSTALLATION
WARNING
Carry out the unpacking, assembly and installation operations described in this
heading with great care.
Failure to observe these instructions may result in damage to the machine and
injury to the operator or other persons.
Remove the original packing material, after having positioned it as shown on the
outside and keep intact so that the machine can be safely shipped at a later
date if necessary.
ATTENTION
The regulations in force concerning safety at work must be complied with when
choosing the installation position.
In particular, the machine must be only be installed and used in protected
environments where there is no risk of dripping onto it.
Ambient conditions in place of operation:
- relative humidity from 30% to 80% (without condensate);
- temperature from 0° to +50°C.
ATTENTION
For the technical specifications, warnings, maintenance and all other
information concerning the monitor, refer to the relative operator manuals
supplied with the machine’s documentation.
WARNING
The machine must not be operated in potentially explosive atmospheres.
IMPORTANT: for correct, safe use of the equipment, users must ensure a lighting
level of at least 300 lux in the place of use.
If the machine is supplied with a number of separate parts that require assembly,
follow the assembly procedures described below.
Fitting the head with the monitor (fig.5)
- Tighten the retainer screw (F, fig.5) and the relative lock-nut on the head
support upright plate.
- Place the head (A, fig.5) on the upright behind the weight-holder lid (E, fig. 5),
fitting the pin into the hole; the monitor screen must be facing towards the front
of the machine.
- Check that the head will turn freely through about 30° ; this means that the
rotation stop has fitted into the seat provided correctly.
- Fix the head rotation pin into its seat, fitting the snap ring, the washer and the
M6 screws (G, fig. 5)
