VINYL LINER INSTALLATION (continued)
10
Installation detail of a bead liner with top track.
Hang the liner on the top of the wall and install the top track to se-
cure.
Start the vacuum cleaner to allow the liner to adhere to the wall and
check for excess tension at the bottom or for wrinkles. Adjust the
liner by removing wrinkles if needed, lift or lower it in order to ensure
a perfect fit.
Fill the pool with water up to the base of the wall before stopping
and removing the vacuum cleaner.
PUMP RETURN FITTING
After you remove the vacuum cleaner, you may install the return fit-
ting. Place the return fitting ring against the liner and adjust it so
that it is perfectly aligned with the hole in the wall. When the ring is
properly positioned and secured, cut the liner in the middle of the
ring.
Insert the return fitting from the inside, placing the first gasket be-
tween the return fitting and the liner and the second between the
wall and the liner. Then tighten the outside ring with large pliers, tak-
ing care not to crease the liner.
BOTTOM DRAIN (optional)
Find the holes through the middle of the liner and screw the ring
and gasket in against the liner before cutting the liner in the middle
of the ring, then screw on the drain cover.
UPRIGHT POST INSTALLATION
11
For the round section:
Clip the uprights to the bottom plates.
Make sure the upright is well snaped into the bottom plate.
Uprights must be installed inside the bottom plate.
