Cornelius S - FILTRATION SYSTEM ASSEMBLY; PARTS LIST

FILTRATION SYSTEM ASSEMBLY
16
PARTS LIST
17
* SEE DRAWING PARTS NEXT PAGE
Assemble skimmer, inlet, drain, filter, pumps, hoses according to separate
manufacturer’s instructions.
Note: See 'Safety Information" Manual.
NOTE: Please confirm quantities with checklist included in each box.
ITEMDESCRIPTION
POOL WALL (finished lenght, inch)
BOLT & NUT FOR 52" (OR 54") WALL
POOL LINER
PLASTIC COUPLER (SOLD SEPARATELY)
TOP SEAT - ROUND SECTION
TOP SEAT- STRAIGHT SECTION
BOTTOM PLATE - ROUND SECTI
ON
UPRIGHT 52'' or UPRIGHT 54''
SEAT CAP - STRAIGHT SECTION
TOP TRACK - ROUND SECTION
TOP TRACK - STRAIGHT SECTION
BUTTRESS ASSEMBLY
BUTTRESS POST
FOOT BEAM
SPLICE BRACKET
PRESSURE PLATE
SPOOL SLEEVE
BOLT 1/2" X 3" X #13 (12,7 mm X 76,2 mm)
NUT 1/2" (12,7 mm)
WASHER 1/2" (12,7 mm)
BOLT CAP COVE
R
FOOT BEAM STYROFOAM BLOCK
TENSION STRAP
1/4" #20 X 5/8" (6,35 mm X 15,88 mm) SCREW & FLANGE NUT
STANDA
RD SCREW ( SCREW #14 , 1" LENGTH)
AA
BB
DD
CC
A
B
C
D
E
F
G
J
K
L
O
Q
R
S
T
U
UU
V
W
X
Y
BB
Z
BOTTOM TRACK - ROUND SECTION
BOTTOM TRACK -
STRAIGHT SECTION
BACK CAP - ROUND SECTION H
SEAT CAP - ROUND SECTION
