Cornell Pump Co.
PUMP SUPPORT REQUIREMENTS
Piping must be properly
supported. Pump is not intended to
carry piping loads.
Support plate for 4WB, 5WB, 3YB & 4YB
Support plate for
all other models.
This pump is equipped with a support plate which is to be used by the customer to provide vertical
support for the pump. If desired, the customer may provide his own support and discard the support
provided. In either case, the pump must be supported.
NOTE: USE PUMP END FRAME BOLT SLOTS FOR SUPPORT ON EMS.
FAILURE TO PROVIDE PROPER SUPPORT OF THE PUMP
WILL VOID THE WARRANTY.
