Raise the pad, C.00093 (Fig. 6) insert the spool on the shaft and adjust nut screw
C.13295V. Pull the thread through the eye of the tension spring C.00945. The
thread must come from below the spool.
Pass the thread hook C.01305 through the big hole of the needleplate C.01707
which is in front of the needle hole.
Catch the thread and pull it up under the needleplate C.01707.
Pass the thread under foot C.00946A which has been raised beforehand.
The thread must be laying towards you.
Start the motor while holding the thread on the table with your left hand as
instructed above just the time to do one stitch so that the needle catches the thread
and let it pass through the plate.
Now, remove the thread from the needle with the curved knife and lay the thread
on the table.
The thread tension is adjusted by pad pressure.
The spool tension can be regulated by raising the lever C.00094 (Fig. 6) or lower
the lever C.00094.
b. The machine threading with a conical spoolholder is the following :
C.00945
E
C
25764
D
FIG. 7
Put the conical Bobbin on the spoolholder A.,(Fig. 8 ), put the yarn through the eye
B (Fig. 8), pass through eye C (Fig. 7) between the tension disc D
(Fig. 7) then pass through the eye E to pass afterwards through the tensionspring
C.00945.
Follow now the instruction as for the cylindrical spoolholder.
