FIG. 3
B
A
FIG. 8
C The machine threading for braiding.
The machine CORNELY LG3 makes every kind of braiding (flat, raised, side sewn
of center sewn) with any braid, cord, ribbon, strung beads, silk, cotton, tergal,
terylene, cellophane, plastics, metal threads etc.
Work with a chain stitch and check that the hook point of the needle is in the same
place as the flat edge of needle tube. Then set the braiding attachment C.10288W
complete .(Fig. 10)
Place the braid, cord or ribbon, etc. on the spool L (Fig. 9) above the head of the
machine. Use small ball chaplet to pass the braid through the needle tube,
entering top opening, going out of the needle tube through the botton opening, then
passing through the suitable guide or nipple. (See Chapter 7.)
Nipple must be in the same direction as the hollow part of the needle tube
The nipple is composed of four parts :
- small tube tightened in the needle tube
- screw.
- Small spring for cloth pressure (if taping)
- guide
The braid must slide freely in the nipple but reasonable. When you ask for a new
guide, never forget to send us a small sample of the braid or cord.
