Instruction Manual
1.0 General Specications
Electrical Requirements
120V model
230V model
120V ± 10%, 50/60Hz, 0.3A
230V ± 10%, 50/60Hz, 0.15A
Fuse 2 x 1A
Speed 3 to 60 rpm
Shaker Orbit 0.75 in. (1.9 cm)
Timer 20 to 120 minutes in 10 minute step, HOLD function
Maximum Load 5 kg
Dimensions 11.6 x 13.4 x 6.3 in. (29.5 x 34 x 16 cm)
Platform Dimensions 11.6 x 11.6 in. (29.5 x 29.5 cm) useable area
Weight 14.5 lbs. (6.6 kg)
Operating Conditions 4°C to 65°C, up to 85% RH, non-condensing
Warranty 5 years
Platform Size 11.8 x 11.8 in. (30 x 30 cm)
This device is intended for use in a basic electromagnetic environment (Basic, class B), and it
is in compliance with IEC 61326-1. Supply cord can be exchanged only with cord 3 x 1.0 mm
2
or
for USA/Canada 3 x 18 AWG.
The Corning® LSE™ Low Speed Orbital Shaker is designed to be safe when operated under the
following conditions:
Indoor use
Altitude up to 2,000 meters
Pollution Degree 2
2.0 Safety Precautions
Do not use the shaker near water. Ensure that water does not get on the device,
particularly during cleaning.
If the unit is used in a manner not specified in this manual, then the unit may
become unsafe to operate and may void the warranty.
This product must be connected to a grounded power outlet for safe functioning.
Use only the power cord supplied with the product.
The equipment will not restart if the main power source is interrupted.
The equipment will restart in cases of mechanical interruption.
Do not expose the shaker to aggressive vapors (e.g., organic solvents).
Do not insert any objects into the shaker (such as a screwdriver or metal rods).
Never operate the shaker without the platform securely attached.
Hazardous samples should be shaken only in appropriate containment vessels.
