-Save these instructions-
CTJTJ1KA
1,000 Lb. Telescoping Transmission
Jack with Air
CTJTJ1KA 6 03/23/20
1-1A Oil Cylinder Assembly 1
1-2 Coupler 1
1-3 Pin 3
1-4 Pedal A 1
1-5 Pin 2
1-6 Washer 1
1-7 Nut 1
1-8 Spring 1
1-9 Pedal B 1
1-10 Pin 2
1-11 Link Rod 2
1-12 Link Rod 1
1-13 RS7200B113A Valve Block (incl. #1-13 - 1-25, 1-28) 1
1-14 O-Ring 2
1-15 Valve Rod 2
1-16 Sealing Washer 2
1-17 Cap 2
1-18 Copper Washer 2
1-19 Screw 2
1-20 Spring 2
1-21 Copper Washer 2
1-22 Coupler 1
1-23 Filter 2
1-24 Snap Ring 1
1-25 Coupler 1
1-26 Plate 1
1-27 Bolt 1
1-28 Cap 1
1-29 Nut 8
1-30 Pin 1
1-31 RS7200C131 Air Pipe 1
1-32 * Y-Seal 1
1-33 Bushing 1
1-34 RS1000134 Piston 1
1-35 Pneumatic Piston Rod 1
1-36 Cylinder Cap 1
1-37 Guide Ring 1
1-38 * Nylon Gasket 2
1-39 * O-Ring 2
1-40 Screw 1
1-41 Screw Cap 1
1-42 * O-Ring 2
1-43 * Nylon Gasket 2
1-44 * O-Ring 2
1-45 Piston Cap 1
1-46 Guide Ring 1
1-47 Oil Container 1
1-48 Hydraulic Piston Rod 1
3-1 Bracket 1
3-2 RS7140C32BK Bracket C - Black 2
3-3 RS7140C33BK Bracket B - Black 1
3-4 RS7140C34BK Bracket A - Black 1
3-5 Retainer Plate Assembly 4
3-5A Retainer Plate 4
3-5B RS7140CSABK Spring Assy (incl. #3-5A - 3-5C, 3-6, 3-7) - Black 4
3-5C Rivet 4
3-6 Pin 4
3-7 Retainer Plate A 3
3-8 Adjusting Bracket 1
3-9 Adjusting Bracket A 1
3-10 RS1000310BK Screw A (incl. #3-10, 3-12, 3-18) Rev. B - Black 1
3-11 RS1000311BK Screw B (incl. #3-11, 3-13, 3-18) Rev. B - Black 1
3-12 Handle B 1
3-13 Handle A 1
3-14 *** Shaft 2
Item No. Part No. Description Qty.
Item No. Part No. Description Qty.
Item No. Part No. Description Qty.
Item No. Part No. Description Qty.
1-49 Oil Cylinder 1
1-50 * Copper Washer 3
1-51 * Steel Ball 2
1-52 Spring 2
1-53 Steel Ball 2
1-54 Screw 2
1-55 * Copper Washer 2
1-56 Bolt 2
1-57 * Steel Ball 1
1-58 * Ball Seat 1
1-59 * Spring 1
1-60 Screw 1
1-61 Washer 1
1-62 Bolt 1
1-63 * Steel Ball 1
1-64 * O-Ring 1
1-65 RS7200B165 Oil Release Valve Rod (incl. #1-64 - 1-67) 1
1-66 Pin 1
1-67 Release Knob 1
1-68 RS1000168BK Valve Block Assembly - Black 1
1-69 Lock Washer 3
1-70 Bolt 2
1-71 RS7200B171BK Pump Seat - Black 1
1-72 RS7200B172BK Pump Cylinder - Black 1
1-73 * O-Ring 2
1-74 * Snap Ring 2
1-75 RS7200B175 Pump Plunger 1
1-76 Pin 1
1-77 Pin 1
1-78 RS7200B178BK Handle Socket (incl. #1-76 - 1-78, 1-3) - Black 1
1-79 RS7200B179BL Handle (incl. #1-79, 1-80) - Blue 1
1-80 Handle Sleeve 1
1-81 Oil Pipe 1
1-82 Washer 1
1-83 Washer 1
1-84 Bolt 1
1-85 Bolt 4
1-86 Bolt 1
1-87 * Throttle Valve 1
1-88 Bushing 1
2-1 RS7140C21 Non-Locking Swivel Caster (incl. #2-1 - 2-3) 2
2-2 Lock Washer 4
2-3 Nut 4
2-4 Leg 4
2-5 Bolt 4
2-6 Lock Washer 4
2-7 RS7140C22 Locking Swivel Caster (incl. #2-2, 2-3, 2-7) 2
RSCTJTJ1KAPLK Product Label Kit (not shown) 1
3-15 *** Shaft 2
3-16 *** Bushing 4
3-17 Pin 4
3-18 Pin 2
3-19 Bolt 1
3-20 Bolt 1
3-21 Lock Nut 2
3-22 RS7140C322 Strap 1
3-23 Bolt 1
3-24 Lock Washer 1
3-25 Washer 1
3-26 ** Bolt 1
3-27 ** Lock Nut 1
3-28 Grip 1
3-29 Washer 2
3-30 Bolt 2
3-31 Snap Ring 4
Only items identified by part number are available for purchase.
* Only available in Seal Kit, RS7200DSK, ** Only available in Bolt Kit, RS7140CBK, *** Only available in Saddle Bearing Kit, RS7140SBK. (2 each of #3-14, #3-15, 4 each of #3-16, #3-17).
PARTS LIST FOR SADDLE ASSEMBLY
