- 19 - EVOSHAKE 500 v2
8 TECHNICAL SPECIFICATIONS
8.1 Technical information
8.2 Dimensions
Power supply Single-phase 220 - 240V ±5%
(Option: 110-120V)
Power 50 Hz
Fuses T 6.3 A (F 10A on 110-120V)
Max power consumption 800 W
Type Vibrational
Clamping function Automatic & self calibrated
Clamp force (kg) Set by can size
Shake time Set by can size
Shaking speed Set by can size
Shaking direction Bi-directional
Type of cans Round / square / oval
Max can diameter 370 mm
Min height 50 mm
Max height 410 mm
Max can weight 40 kg
Multiple can handling Yes
Loading height from floor 430 mm
Noise level Machine noise emission: < 70dB (A)
Environment working conditions Temperature: between 10°C and 40°C
Relative humidity: 5% - 85%
Machine Packed machine
Depth 673 mm 850 mm
776 mm
with front loading area
Width 600 mm 800 mm
Height 1160 mm 1330 mm
Footprint
0.40 m
2
0.68 m
2
0.46 m
2
wih front loading area
Weight 214 kg 246 kg
