corob EVOSHAKE 500 V2 - Usable Cans; Identifying Information

EVOSHAKE 500 v2 - 4 -
2.3 Usable cans
2.4 Identifying information
The product identification data is printed on the type shield behind the
machine, see figure 3-3 on page 5. The type shield is indicating:
• Manufacturer’s name and address
•Marking
• Machine model
•Year of manufacture
• Serial number (S/N)
• Electrical specifications
Can handling features
Type of cans Round / square / oval
Max can diameter 370 mm
Min. height 50 mm
Max height 410 mm
Max can weight 40 kg
Multiple can handling Yes
Loading height from floor 430 mm
dd
Do not remove or tamper with the identification plate in any
way.
Figure 2-2: The machine serial
number, S/N, is in the type shield.
