n
Remove thumbscrews and corresponding slot cover(s)
n Install the add-on card & secure with thumbscrew
Installing the PCI-E/PCI Cards

Installing the Power Supply (PSU)
n Place PSU on the bottom of the case
n Align holes & secure with screws
n NOTE: PSU can be installed in either
fan up or fan down orientation


Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Corsair 200r and is the answer not in the manual?

Corsair 200r Specifications

General IconGeneral
TypeMid Tower
Motherboard SupportATX, Micro-ATX, Mini-ITX
MaterialSteel, Plastic
Expansion Slots7
Cooling SupportFront: 2 x 120mm, Top: 2 x 120mm, Rear: 1 x 120mm, Bottom: 1 x 120mm
Front I/O Ports2 x USB 3.0, 1 x Headphone, 1 x Microphone
Maximum GPU Length420mm
Maximum CPU Cooler Height165mm
Cooling1 x 120mm Rear Fan
