Corsair AX1500i User Manual

7 8
AXi SERIES
™
AXi SERIES
™
Important safety information
CAUTION ELECTRIC SHOCK HAZARD!
1. Install in accordance with all manufacturer instructions and safety warnings.
Failure to do so may result in damage to your power supply or system, and may
cause serious injury or death.
2. High voltages are present in the power supply. Do not open the power supply case
or attempt to repair the power supply; there are no user-serviceable components.
3. This product is designed for indoor use only.
4. Do not use the power supply near water, or in high temperature or high humidity
environments.
5. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus that produce heat.
6. Do not insert any objects into the open ventilation or fan grill area of the power supply.
7. Do not modify the cables and/or connectors included with this power supply.
8. If this power supply uses modular cables, use only manufacturer supplied cables.
Other cables might not be compatible and could cause serious damage to your
system and power supply.
9. The 24-pin main power connector has a detachable 4-pin connector. This 4-pin
connector is not a P4 or ATX 12V connector. Do not force this cable in the P4 or
ATX +12V socket on the motherboard.
10. Failure to comply with any manufacturer instructions and/or any of these safety
instructions will immediately void all warranties and guarantees.
Safety and agency approvals
Agency Standard
FCC FCC Rules Part 15, Class B
ICES ICES-003
CE EN 55022:2006 + A1:2007, Class B
EN61000-3-2:2006 + A1:2009 + A2:2009 Class A
EN61000-3-3: 2008
EN55024:1998 + A1:2001 + A2:2003
IEC61000-4-2
IEC61000-4-3
IEC61000-4-4
IEC61000-4-5
IEC61000-4-6
IEC61000-4-11
UL / CUL UL 60950-1
CSA C22.2 NO. 60950-1
C-Tick / RCM AS/NZS CISPR 22:2009
AS/NZS 4417
TUV EN 60950-1
CB IEC 60950-1
CU R IEC 60950-1-2005
R 51318.22-99
R 51318.24-99
R 51317.3.2-2006
R 51317.3.3-2008
KC Mark K 60950-1(2006-12), K00022(2009-12), K00024(2009-12)
ROHS 2002/95/EC, Restriction of Hazardous Substances Directive
WEEE 2002/96/EC, Waste Electrical and Electronic Equipment Directive
ROHS (China) China Order No.39, Administration on the Control of Pollution Caused By
Electronic Information Products
REACH Regulation EC No.1907/2006 concerning the Registration, Evaluation,
Authorization, and Restriction of Chemicals

Corsair AX1500i Specifications

General

Efficiency	94 %
Total power	1500 W
Power factor	0.99
Input current	15 A
AC input voltage	90 - 264 V
AC input frequency	50 - 60 Hz
Combined power (-12V)	9.6 W
Combined power (+3.3V)	180 W
Combined power (+5Vsb)	17.5 W
Max output current (+12V)	125 A
Max output current (-12V)	0.8 A
Power protection features	Over current, Over voltage, Short circuit, Under voltage
Max output current (+3.3V)	30 A
Max output current (+5Vsb)	3.5 A
Maximum input current (@110V)	+12V, +3.3V, +5V, +5Vsb, -12V A
Power Factor Correction (PFC) type	Active
Fan diameter	140 mm
Fan location	Top
On/off switch	Yes
Product color	Black
Number of fans	1 fan(s)
Cabling type	Fully-Modular
Motherboard power connector	24-pin ATX
Floppy drive power connector	2
Number of SATA power connectors	20
PCI Express power connectors (6+2 pin)	10
Peripheral (Molex) power connectors (4-pin)	12
Purpose	PC
ATX version	2.4
EPS version	2.92
Noise level	- dB
Certification	cTUVus, TÜV, CCC, CE, RCM, CU, KC Mark, FCC
80 PLUS certification	80 PLUS Titanium
Mean time between failures (MTBF)	100000 h
Power supply unit (PSU) form factor	ATX

Weight and Dimensions

Depth	225 mm
Width	150 mm
Height	86 mm
