Corsair AX860 User Manual

4140
AX SERIES
™
AX SERIES
™
   
FCC FCC Rules Part 15, Class B
ICES ICES-003
CE EN 55022:2006 + A1:2007, Class B
EN61000-3-2:2006 Class D
EN61000-3-3: 1995 + A1:2001 + A2:2005
EN55024:1998 + A1:2001 + A2:2003
IEC61000-4-2:1995 + A1:1998 + A2:2000
IEC61000-4-3:2006
IEC61000-4-4:2004
IEC61000-4-5:2005
IEC61000-4-6:2003 + A1:2004 + A2:2006
IEC61000-4-8:1993 + A1:2000
IEC61000-4-11:2004
UL / CUL UL 60950-1
AS/NZS 4417
TUV EN 60950-1
CB IEC 60950-1
CCC GB4943
GB9254
GB17625.1
BSMI CNS14336
CNS13438
GOST R IEC 60950-1-2005
R 51318.22-99
R 51318.24-99
R 51317.3.2-2006
R 51317.3.3-99
IRAM IEC 60950-1
KC Mark K60950-1, K00022, K00024
ROHS 2002/95/EC, Restriction of Hazardous Substances Directive
WEEE 2002/96/EC, Waste Electrical and Electronic Equipment Directive
ROHS China Order No.39, Administration on the Control of Pollution Caused By
(China) Electronic Information Products

Corsair AX860 Specifications

General

Efficiency	92 %
Total power	860 W
Power factor	0.99
AC input voltage	90 - 264 V
AC input frequency	50 - 60 Hz
Power protection features	Over current, Over voltage, Short circuit, Under voltage
Maximum input current (@110V)	+12V, +3.3V, +5V, +5Vsb, -12V A
Power Factor Correction (PFC) type	Active
Fan diameter	120 mm
Fan location	Top
On/off switch	Yes
Product color	Black
LED indicators	No
Number of fans	1 fan(s)
Cabling type	Fully-Modular
Connector(s)	BS1363
Motherboard power connector	24-pin ATX
Number of SATA power connectors	12
PCI Express power connectors (6+2 pin)	6
Peripheral (Molex) power connectors (4-pin)	8
Safety	cTUVus, CE, CB, FCC Class B, TÜV, CCC, C-tick
Purpose	PC
ATX version	2.31
EPS version	2.92
Noise level	- dB
80 PLUS certification	80 PLUS Platinum
Mean time between failures (MTBF)	100000 h
Power supply unit (PSU) form factor	ATX
Power supply type	AC/DC
Dimensions (WxDxH)	150 x 160 x 86 mm

Weight and Dimensions

Depth	160 mm
Width	150 mm
Height	86 mm
