Corsair AX860 User Manual

54
AX SERIES
™
AX SERIES
™
Congratulations on the purchase of your new Corsair AX Series High Performance
ATX power supply.
The Corsair AX series is quiet, powerful, and is certified 80 PLUS® Platinum, for up to
92% eciency.
Product Features
80 PLUS® Platinum Eciency
The AX series is 80 PLUS® Platinum certified, for up to 92% eciency. This means less power
drawn from the wall, less heat generated, and lower electricity bills.
Fanless operation at Low Loads
The AX series is so ecient that the temperature-controlled ball-bearing fan doesn’t even spin up
at low loads. As the load rises, the fan will spin as needed.
Fully modular cables
Fully modular means easy installation. Plug the cables into your hardware first, then route them
down to the PSU area of your case for easy, quick, clean cable routing.
Reliable, continuous power
Rated at a server-like 50C, the AX series features industrial grade components and specifications,
painstakingly managed by Corsair engineers to guarantee its industry-leading seven year
warranty.
Oustanding Compatibility
Regardless of your system layout, the AX series features long cables and plenty of connectors to
run just about anything you need. PSU located on the bottom of your case? Don’t worry, in most
cases, the cables should reach easily.
User-selectable fan mode switch
If you don’t need fanless operation, , ip the switch. The [OTHER] mode oers standard operation
where the fan is turned on full time. Don’t worry, though. It’s still thermally controlled, so it’s not
running at full speed all the time.
Power Supply Specifications
• 150mm(W) x 86mm(H) x 160mm(L)
• MTBF: 100,000 Hours
Package Contents
• Corsair AX Series power supply unit
• Modular cable set
• User Manual
• AC power cord
• Cable ties
• Mounting screws
• Corsair case badge
• Carrying bag
AX860
MODEL
75-001305
AC INPUT RATING
AC Input 100-240V
Input Current 11-5.5A
Frequency 50-60Hz
DC OUTPUT RATING
MAX LOAD MAX OUTPUT
+3.3V 25A
125W
+5V 25A
+12V 71A 852W
-12V 0.5A 6W
+5Vsb 3A 15W
Total Power 860W
Corsair AX860 Cable Configuration
AX860
Qty Length
1 610mm ± 10mm ATX Cable 24-PIN (20+4)
2 650mm ± 10mm EPS/ATX12V Cable 8-PIN (4+4)
6
600mm ± 10mm;
750mm ± 10mm
PCI-E Cable 8PIN (6+2)
2 700mm ± 10mm SATA Cable (4 SATA)
1 850mm ± 10mm SATA Cable (4 SATA)
2 750mm ± 10mm Peripheral Cable (4 PIN)
2 101mm ± 5mm Floppy Drive Cable (4 PIN)

Corsair AX860 Specifications

General

Efficiency	92 %
Total power	860 W
Power factor	0.99
AC input voltage	90 - 264 V
AC input frequency	50 - 60 Hz
Power protection features	Over current, Over voltage, Short circuit, Under voltage
Maximum input current (@110V)	+12V, +3.3V, +5V, +5Vsb, -12V A
Power Factor Correction (PFC) type	Active
Fan diameter	120 mm
Fan location	Top
On/off switch	Yes
Product color	Black
LED indicators	No
Number of fans	1 fan(s)
Cabling type	Fully-Modular
Connector(s)	BS1363
Motherboard power connector	24-pin ATX
Number of SATA power connectors	12
PCI Express power connectors (6+2 pin)	6
Peripheral (Molex) power connectors (4-pin)	8
Safety	cTUVus, CE, CB, FCC Class B, TÜV, CCC, C-tick
Purpose	PC
ATX version	2.31
EPS version	2.92
Noise level	- dB
80 PLUS certification	80 PLUS Platinum
Mean time between failures (MTBF)	100000 h
Power supply unit (PSU) form factor	ATX
Power supply type	AC/DC
Dimensions (WxDxH)	150 x 160 x 86 mm

Weight and Dimensions

Depth	160 mm
Width	150 mm
Height	86 mm
