Corsair Carbide series User Manual

CARBIDE SERIES
®
SPEC-06
ENGLISH
Case featuresAccessory kit contents
A — Windowed side panel
B — 2 x 120mm fans
C — Dust filters
D — Top dust filter
E — Removable SSD trays
F — HDD trays
G — Front bezel
H — Solid side panel
Cable ties
Hex screw
Long fan screws
Double side adhesive tape
MBD / HDD screws
B x16
Motherboard standoffs
Hex screw tool
ODD / SSD screws
C x16
Fan screws (short)
A x16
D
G HE
A
B F
C
B
C
D x1 E x8 F x6
G x1 H x1 I x4
43

Corsair Carbide series Specifications

General

Type	Mid Tower
Motherboard Support	ATX, Micro-ATX, Mini-ITX
Material	Steel, Plastic
Expansion Slots	7
Front I/O Ports	1 x Headphone, 1 x Microphone
Radiator Support	120mm rear
Drive Bays	2 x 2.5", 2 x 3.5"
