Corsair H105 User Manual

1
Installing the Intel Backplate
• For LGA 115X installation, slide the backplate pins inside.
(figure 1)
• For LGA 1366 installation, slide the backplate pins
outside. (figure 1)
• Install the assembled backplate. (figure 2)
Note: Intel LGA 2011 does not require back plate
installation. Proceed to step 2.
LGA 1366
LGA
115X
figure 1
figure 2
