Page #67 background imageLoading...
Page #67 background image
129 130
RMx SERIES
RMx SERIES
Corsair RMx シリーズの高性能 ATX 源をご購入いただき、
ありがとうございます。
Corsair RMx シリーズは、専用設計されたファンとゼロ RPM ファンモード
を搭する、静音化のためのチューニングが施されたハイエンド電源です。80
PLUS ゴールド認証を取得しており、電気コストを低く抑えることができま
す。フルモジュラー式のブラックケーブルが採用されており、素早くすっきり
とまとめることができます。日本製の105℃コンデンサを全面採用しており、
信頼性が不可欠なハイエンドPCにとって理想の製品です。
安全機能と保護回路
過電圧保護(OVP)
ATX 仕様に基づき、12V5V および 3.3V DC 出力には過電圧保護(OVP)回路が
設けられています。OVP は、電源メーカーが定めた定格 DC 出力を超える電圧が流れ
た場合に電源ユニットを遮断します。保護回路が作動する最小電圧は、+12V レールで
13.4V、+5V レールで 5.74V、および 3.3V レールで 3.76V と定められています。
過電流保護(OCP
RMx シリーズでは、3.3V、5V および 12V の各レールに OCP 回路が設けられていま
す。OCP は、DC 出力電圧を安全動作の範囲内に制御することを目的としています。
過熱保護(OTP
OTP は、内部温度が一定のレベルに達したときに PSU を遮断します。通常、内部電流過
負荷またはファンの故障が原因で作動します。
ショート保護(SCP
ショート状態は、0.1 オーム未満の出力インピーダンスとして定義されていま
す。3.3V5V および 12V の各レールが他のレールやアース線とショートした際に電源
を遮断する役目は主に SCP が担っています。また、電源ユニットや PC 部品をショート
による損傷から保護します。
製品仕様
RMx .................... 
RMx ...................... 
RMx ...................... 
RMx ...................... 
RMx ...................... 
組み付け ...................... 
製品保証 ...................... 
安全情報と適合規格 ..... 

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Corsair RM650x and is the answer not in the manual?

Corsair RM650x Specifications

General IconGeneral
Total power650 W
Input current10 - 5 A
AC input voltage100 - 240 V
AC input frequency47 - 63 Hz
Combined power (+12V)648 W
Combined power (-12V)9.6 W
Combined power (+3.3V)130 W
Combined power (+5Vsb)15 W
Max output current (+12V)54 A
Max output current (-12V)0.8 A
Max output current (+3.3V)25 A
Max output current (+5Vsb)3 A
Cabling typeFully-Modular
Motherboard power connector20+4 pin ATX
Motherboard power cable length610 mm
Peripheral (Molex) power connectors (4-pin)4
PurposePC
Silent modeYes
Bearing technologyRifle
80 PLUS certification80 PLUS Gold
Power supply unit (PSU) form factorATX
Cooling typeActive
Product colorBlack
Number of fans1 fan(s)
Sustainability certificatesLow Voltage Directive (LVD), RoHS
Cables includedAC, DC
Weight and Dimensions IconWeight and Dimensions
Depth160 mm
Width150 mm
Height86 mm
Weight1620 g
