General| Hold time | 16 ms |
|---|---|
| Total power | 750 W |
| Power factor | 0.99 |
| Input current | 5 - 10 A |
| AC input voltage | 100 - 240 V |
| AC input frequency | 47 - 63 Hz |
| Combined power (-12V) | 9.6 W |
| Combined power (+3.3V) | 150 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+12V) | 62.5 A |
| Max output current (-12V) | 0.8 A |
| Power protection features | Over current, Over power, Over voltage, Short circuit, Under voltage |
| Max output current (+3.3V) | 25 A |
| Max output current (+5Vsb) | 3 A |
| Purpose | PC |
| ATX version | 2.4 |
| EPS version | 2.92 |
| Noise level | 23 dB |
| Bearing technology | Rifle |
| 80 PLUS certification | 80 PLUS Gold |
| Mean time between failures (MTBF) | 100000 h |
| Power supply unit (PSU) form factor | ATX |
| Noise level (quiet mode, 50%) | 12.4 dB |
| Fan speed | 745 RPM |
| Fan diameter | 140 mm |
| Product color | Black |
| Number of fans | 1 fan(s) |
| Cabling type | Fully-Modular |
| EPS power connector (8-pin) | Yes |
| Motherboard power connector | 20+4 pin ATX |
| Floppy drive power connector | 1 |
| Number of SATA power connectors | 8 |
| PCI Express power connectors (6+2 pin) | 4 |
| Peripheral (Molex) power connectors (4-pin) | 7 |
| Sustainability certificates | RoHS |
Weight and Dimensions| Depth | 180 mm |
|---|---|
| Width | 150 mm |
| Height | 86 mm |
| Weight | 1930 g |
