Corsair SF600 User Manual

5 6
SF SERIES
™
SF SERIES
™
Max Load Max Output
Model RPS0025 +3.3V 15A
100W
Part No. CP-9020104 /75-011263 +5V 20A
AC Input Rating 100-240V +12V 37.5A 450W
Input Current 10A-5A -12V 0.3A 3.6W
Frequency 47˜63Hz +5Vsb 2.5A 12.5W
Total Power: 450W
SF450
Dimensions: 125mm (W) x 63.5 mm (H) x 100mm (L)
Package contents
• Corsair SF Series power supply unit
• AC power cord
• DC Modular cable set
• DC Modular cable storage bag
• Cable ties
• Corsair case badge
• User manual
Corsair SF450 DC cable listing
Corsair SF450 power table
Corsair SF450 power supply eciency
Corsair SF450 power supply fan noise curve
input 115Vac input 230Vac
93
91
89
87
85
83
81
79
77
75
10010
5020
35
30
25
20
15
10
5
0
0% 100%20% 40% 60% 80%
93
91
89
87
85
83
81
79
77
75
10010
5020
35
30
25
20
15
10
5
0
0% 100%20% 40% 60% 80%
% EFFICIENCY
SYSTEM LOAD
Fan Noise (db)
SYSTEM LOAD
Qty Description Total Length
1
SFX Cable 24 pin (20+4)
Connectors Per Cable
300mm
(± 10mm)
1
Total Connectors
1
1
EPS/SFX12V 8 pin (4+4) cable
Connectors Per Cable
400mm
(± 10mm)
1
Total Connectors
1
2
PCIe 8 pin (6+2) cable
Connectors Per Cable
400mm
(± 10mm)
1
Total Connectors
2
1
SATA cable (4 SATA)
Connectors Per Cable
445mm
(± 10mm)
4
Total Connectors
4
1
Peripheral cable (4-pin)
Connectors Per Cable
445mm
(± 10mm)
4
Total Connectors
4
450mm 100mm 100mm 100mm
100mm 115mm 115mm 115mm
550mm 100mm 100mm 100mm
100mm 115mm 115mm 115mm
650mm
400mm
300mm
300mm
600mm
400mm

Corsair SF600 Specifications

General

Total power	600 W
AC input voltage	100 - 240 V
AC input frequency	47 - 63 Hz
Power protection features	Over power, Over voltage, Overheating, Short circuit, Under voltage
Purpose	PC
ATX version	2.4
EPS version	2.92
Silent mode	Yes
Bearing technology	Rifle
80 PLUS certification	80 PLUS Platinum
Supported motherboard form factors	ATX
Power supply unit (PSU) form factor	SFX
Cables included	AC, DC
Cabling type	Fully-Modular
SATA power cable length	450 mm
Motherboard power connector	24-pin ATX
Motherboard power cable length	300 mm
PCI Express power cable length	400 mm
Number of SATA power connectors	4
Peripheral (Molex) power cable length	330 mm
PCI Express power connectors (6+2 pin)	2
Cooling type	Active
Fan diameter	92 mm
Fan location	Top
Number of fans	1 fan(s)

Weight and Dimensions

Weight	860 g
