6 | PARTS LIST
III. PARTS LIST
No. Description Qty
1 Welded Rear Horizontal 1
Stick Ground Pipe
2 Welded Right Floor Pipe 1
3 Welded Left Floor Pipe 1
4 Welded Barbell Rack Frame 1
5 Welded Left Anterior Vertical Tube 1
6 Welded Right Front Vertical Tube 1
7 Welded Rear Vertical Pipe 2
8 Welded Upper Left Tube 1
9 Welded Upper Right-side Tube 1
10 25 Pipe Guide Rod 2
11 Welded Horizontal Pipe 1
of Hanging Ring Sheet
12 Selection Lever 1
13 Small Single Pulley Frame 1
14 Welded Front Upper Beam Pipe 1
15 Welded Upper Horizontal Pipe 1
16 Left Primer 1
17 Right Primer 1
18 Welded Hold Rod 1
19 Smith Guide Rod 2
20 Welded Sliding Sleeve 2
21 Left Safety Bar 1
22 Right Safety Bar 1
23 Barbell Sleeve 2
24 Welded Left Adjustment U-seat 1
25 Welded Right Adjustment U-seat 1
26 Welded Bird Pulley Box 2
27 Rope Buckle Silk 2
28 Welded Pattern Plate 1
29 Landmine Post 1
30 Barrel Steering Frame 1
31 Welded Double U-seat 1
32 Double Bar Left Hand 1
33 Double Bar Right Hand 1
34 Left Shelf 1
No. Description Qty
35 Right Shelf 1
36 Left Protection Frame 1
37 Right Protection Frame 1
38 Welded Sleeve Hanging Rod 4
39 Landmine Handle 1
40 Straight Row Bar Attachment 1
41 Curl Bar Handle 1
42 Counterweight Block (Large) 6
43 Counterweight Block (Small) 1
44 Slider Adjustment Sheet 4
45 Internal Casing 2
46 Ball Stud 2
47 Sleeve 6
48 Spring Collar 4
49 Large Shock Pad 6
50 Weight Selection Pin 1
51 M10 Knob 1
52 Big Pulley 20
53 Small Pulley 1
54 Type C Buckle 2
55 Hand Pull Ring 2
56 Wire Rope A 2
57 Wire Rope B 1
58 25 Short Light Axis 20
59 Bolt M10X70 20
60 Bolt M10X90 12
61 Bolt M10X20 12
62 Bolt M10X45 21
63 Φ10 Flat Gasket 122
64 M10 Nut 57
65 Φ10 Flat Pad 2
66 Bolt M10X16 20
67 Bolt M8X16 4
68 Bolt M8X40 2
69 Bolt M10X80 2
