PARTS LIST |
III. PARTS LIST
Key No. Description Qty.
1 Left Butterfly Arm 1
2 Right Butterfly Arm 1
3 Back Rest Upright Column 1
4 Cable Rail Bottom Feet 1
5 Cable Rail Top Frame 1
6 Weight Holder 1
7 Foot Plate 2
8 Back Rest 1
9 Arm Pads 2
10 Sleeve 2
11 Cable Rods 2
12 Butterfly Arm Frame 1
13 Joint Frame Bottom 1
14 Joint Frame Top 1
15 Pulley 6
16 Cable 4370mm 1
17 Cable 2895mm 1
18 Pulley Diaphragms 2
19 Nut Cap 2
20 Collars 2
21 Large Shock Pad 2
Key No. Description Qty.
22 Knob 1
23 Frame Shaft 1
24 Connecting Plate 2
25 Flat Connecting Sheets 2
26 Pulley Block 2
27 Cross Pulley Block 1
28 Screw Sleeve Welding 1
29 Connecting Plate 1
30 Bolt M10x90mm 6
31 Bolt M10x70mm 13
32 Bolt M10x60mm 1
33 Bolt M10x45mm 6
34 Bolt M10x20mm 4
35 Bolt M8x65mm 6
36 Bolt M6x35mm 2
37
Large Washer Ø10
2
38
Flat Washer Ø10
56
39
Washer Ø8
6
40 Nut M10 28
41 Nut M5 2
