6 | PARTS LIST
III. PARTS LIST
No. Description Qty
1 Back Long Ground Piece 1
2 Middle Ground Piece 1
3 Front Ground Piece 1
4 T Ground Piece 1
5 Foot Plate 1
6 Small Side Ground Piece 2
7 Guide Rod 2
8 Selector Rod 1
9 Counterweight Block 1
10 Upright Column 1
11 Seat Support Tube 1
12 Leg Arm 1
13 Upper Column 1
14 Connected Frame 1
15 Left Butterfly Arm 1
16 Right Butterfly Arm 1
17 Seat Adjustment Frame 1
18 Preacher Pad Frame 1
19 Backrest Pad 1
20 Seat Cushion 1
21 Preacher Pad 1
22-1 Top Cable 1
22-2 Bottom Cable 1
22-3 Middle Cable 1
23 Pulley 18
24 Lat Pull Down Handle 1
25 Straight Bar Handle 1
26 Tricep Rope 1
27 Shift Tube 1
28 Bubble Cotton Tube 2
29 Foam (Φ100x175) 4
30 Left Plate Cover 1
31 Right Plate Cover 1
No. Description Qty
48 Top Cable Cover 2
55 Pull Handle 2
57 Weight Blocks 12
53-1 Position the Pulley Frame 2
53-2 Slide Wheel Adjustment Plate 2
53-3 Connecting Plate 2
53-4 Cross Pulley Frame 1
53-5 L-Pin 1
53-8 Revolving Shaft (57mm) 1
53-9 Revolving Shaft (100mm) 1
54-1 Rubber Cushion 2
54-3 Foam Plug 4
54-4 Knob Pin 2
54-5 Slider Liner 8
54-6 Matching Weight Limit 2
54-9 Chain 200mm 1
54-10 Chain 400mm 1
54-11 Type C Buckle 4
54-12 Caribena Hook 1
56-1 Bolt M10*90 10
56-2 Bolt M10*70 10
56-3 Bolt M10*20 8
56-4 Bolt M10*45 16
56-7 Bolt M8*16 16
56-8 Bolt M8*40 2
56-10 Bolt M8*85 2
56-12 Φ10 Flat Gasket 106
56-13 Φ10 Increase the Flat Pad 4
56-14 M10 Locknut 38
56-15 M8 Nut 6
56-16 Bolt M6*10 3
56-17 M6 Nut 3
