Cortex V1 - Step 3: Attach Bottom Cross Brace

7ASSEMBLY INSTRUCTIONS |
STEP 3
1. Attach the Bottom Cross Brace (#1) to the Rear Left Stabiliser (#2) and Rear Right Stabiliser (#3) using
the bolts shown. Make sure that the narrower edge of the Cross Brace (#1) is closer to the Stand Leg (#4)
uprights.
NOTE: Do not tighten bolts.
4
4
2
3
10
1
12
11
