Changing Position of Shoulder Harness Strap
1. Fully Loosen
Harness Strap
Push down on
harness release
lever (under fl ap on
front of seat pad)
while pulling out on
harness straps as
shown.
2. From Back,
Remove Harness
Strap Loops From
Splitter Plate
3. Pull Harness Strap
Out of Shoulder
Harness Slots
4. Rethread Harness
Strap into Correct
Shoulder Harness
Slots For Your Child
See page 6 for fi t
guidelines.
5. Attach Harness
Strap Loops to
Splitter Plate
As Shown
Sewn ends of the
harness strap loops
MUST face towards you.
DO NOT twist harness strap or harness
adjustment strap.
Make sure the
loops are fitted
COMPLETELY ON
both sides of the
splitter plate.
WARNINGS: Make sure that
harness height is correct for your
child’s size.
Do not use this child
restraint forward facing
if the tops of your child’s
ears are above the top of
the child restraint.
Failure to follow these steps can
result in serious injury or death.
