Cosco Scenera - Understanding Your Child Restraint

56
PUSH
A. Infant Insert
(on select models)
B. Cup Holder
(on select models)
C. Body Pillow
(on select models)
D. Harness Adjustment
Lever (under flap)
E. Harness
Adjustment Strap
A-4 Understanding Your Child Restraint
continued on next page.
A.
C.
F. Upper Harness Slots
G. Chest Clip
H. Harness Straps
I. Buckle Tongues
J. Buckle
K. Lower Harness Guides
L. Buckle Strap
M. Buckle Strap Slots
D.
E.
G.
I.
L.
K.
H.
J.
B.
Front View
Harness System Detail
M.
F.
A. Before You Begin
Pad layout may not be the same as shown. See section C-9 for other
possible accessory options.
