Cosco Scenera - Page 5

7
8
4360-0681
Line to be Level To Ground
Rear-Facing Only
Back View
A. Tether Strap
with Adjuster
and Hook
B. Splitter Plate
C. Tether Attachment for
Storage
D. Instruction Manual
Storage
(in recline stand)
E . Recline Stand
A.
F. UAS* Attachment
for Storage
(behind pad)
G. Shell
H. Forward-Facing
Belt Path
I. Rear-Facing Belt
Path
J. Rear Facing Level-
To-Ground Line
K. UAS* Belt
L. UAS* Adjuster
M. UAS* Hook
B.
D.
I.
Side View
C.
H.
E.
F.
J.
L.
K.
M.
Tether Adjuster
Tether Hook
*Universal Anchorage System (UAS)
K.
G.
C.
F.
A.
A. Before You Begin
