- 10 -
continue the inflation procedure with the wheel inside a special protection cage
( commercially available).
NEVER exceed the maximum inflation pressure given by the tire manufacturer.
3) ALWAYS keep hands and entire body back from inflating tire.
ONLY specially trained personnel are allowed to perform these operations.
Do not allow other to operate or be near the tire changer
7. FRL INSTRUCTIONS
FRL include air filter, pressure reducer and lubricator.
The filter is used for avoiding water getting into the tire changer with the air.
The pressure reducer can stabilize pressure and prevent the valves, cylinders and other
moving parts from impact by the input air pressure instability.
Lubricator can lubricate the moving parts that are inconvenient to lubricate.
In all, FRL can prolong the tire changer's service life greatly.
1) AIR INLET DIRECTION
Air inlet is marked .
2) SPECIFICATION
Applicable fluid Air
Max working pressure 1.0MPa
Environment temperature ＆ Fluid temperature 5℃～60℃
Recommended applicable oil 50W hydraulic oil
Setting pressure range 0.05~1.0 Mpa
3) OPERATION AND MAINTENANCE
This is pressure reducer.
Open (pull up) the knob
and regulate the air
pressure by turning the
knob.
Setting press range:
0.05~1.0MPa.
Close (Push
down) the knob
to locking the
air pressure.
This is filter to separate water
from air. Check the level of water
in the filter. We recommend the
water level never reach above
the 50% of the glass volume.
When necessary, drain the water
by pulling the locking ring.
