No. Part Code Qt. Part Name No. Code Qt. Part Name
1 C2110101 1 Body 267 GB/T 95 4 Washer Φ12
2 C2110615 1 Front cover 268 GB/T 95 4 Flat spacer for chuck
3 GB/T 70 4 Screw M5×10 269 C2880125 1 Washer for square turntable
4 GB/T 70 2 Screw M6×35 270 GB/T 894 1 Circlip φ65
5 GB/T 93 2 Washer φ6 271 GB/T 78 4 Bolt M12x40
6 GB/T 70 4 Screw M6×10 272 C288TR.01.55.01 2 Lower slide guide with pin
7 C2110143 1 Left cover 273 C2880162 2 Complete clamping cylinder
8 C2110170 1 Rubber plug φ21 274 GB/T 95 4 Washer Φ12
9 C2110171 2 Rubber plug φ45 275 GB/T 894.1 4 Circlip φ12
10 C2110159 1 Oil box 276 GB/T 95 4 Washer Φ12
11 GB/T 70 6 Screw M8×20 277 GB/T 894.1 4 Circlip φ12
12 GB/T 93 6 Washer φ8 278 C233016001 2 Front flange
13 C2110113 1 Rubber wheel support 279 PC08-01 2 Union 8-1/8"
14 C211010105 4 Rubber foot 280 JB/T 6997 2 V-seal Y28X20X10
15 C2110158 1 Bead liftng lever 281 JB1092 2 O-ring φ71X2.65
282 C233011906 2 Piston
101 C2110138 1 Vertical column 283 GB/T 95 2 Washer Φ12
102 C2110135 1 Column pin 284 GB/T 1337 2 Self-locking nut M12
103 GB/T 95 1 Self-locking nut M16 285 C2880016203 2 Cylinder casing
104 GB/T41 1 Washer φ16 286 C288016201 8 Tightener
105 C2110137 1 Column adjusting screw 287 JB1092 2 O-ring φ71X2.65
106 C2110133 1 Locking block handle bar 288 GB/T 95 16 Washer Φ8
107 C2110127 1 Locking block support 289 GB/T 41 16 Nut M8
108 C2110134 1 Cone washer 290 PL08-01 2 L-union 8-1/8"
109 GB/T 93 2 Washer φ8 291 C233016203 2 Rear flange
110 GB/T 70 2 Screw M8×25 292 C288016202 2 Cylinder rod
111 C2110128 1 Locking block
112 GB/T 41 1 Nut M12 301 C2110353 1 Union 8-M12
113 GB/T 78 1 Screw M12×30 302 C211010607 1 Washer φ12
114 GB/T 70 1 Screw M8×50 303 C211010603A 1 Bead breaker cylinder casing
115 C2110132 1 Knob 304 GB/T 1337 1 Self-locking nut M16
116 C2110129 1 Plastic cover 305 GB/T 95 1 Washer φ16
117 C2110131 1 Spring 306 JB1092 1 O-ring φ16
118 C2110130 1 Locking plate 307 GB/T 95 1 Washer φ16
119 C2110126 1 Horizontal arm 308 JB1092 2 O-ring φ180
120 C2110125 1 Hexagonal vertical arm 309 C211010606 1 Bead breaker cylinder lid (front)
121 C2110124 1 Buffer bush 310 C211010601 1 Bead breaker cylinder rod
122 C211012302 1 Mounting head plastic protector 311 JB/T 1091 2 V-seal
123 C2110124 1 Munting head 312 C211010602 1 Piston
124 GB/T 119 1 Pin 313 GB/T 41 12 Nut M6
125 GB/T 78 1 Screw M10×25 314
126 GB/T 95 1 Washer φ10 315 C2110114 1 Shovel
127 GB/T 78 4 Screw M12×15 316 C2110111 1 Bead breaker arm pin (front)
128 GB/T 41 4 Nut M10 317 GB/T 1337 1 Self-locking nut M20
129 GB/T 95 4 Washer φ10 318
130 GB/T 73 4 Spring Washer ￠10 319 GB/T 894.1 1 Circlip φ16
131 C2110123 1 Complete mounting head 320 GB/T 96 1 Washer φ16
321 C2110105 1 Bead breaker arm
250 C2110163 1 Cap 322 C2110142 1 Bead breaker arm pin (rear)
251 GB/T 5781 1 Bolt M16x40 323 C2110168 1 Rotating pin
252 C2110120 1 Turntable washer 324 GB/T 1337 1 Self-locking nut M12
253 C2110144 4 Jaw 325 GB/T 95 2 Washer φ12
254 C288TR.01.55.05 4 Slide 326 GB/T 5287 1 Washer φ8
255 GB/T 78 4 Bolt M8x30 327 GB/T93 1 Spring washerφ8
256 C288TR.01.55.02 4 Upper slide guide 328 GB/T 5783 1 Screw M8×15
257 C288TR.01.55.04 4 Metal guide 329 C2110108 1 Cushion
258 GB/T 78 8 Bolt M8x20 330 C2110104 1 Spring
259 C288TR.01.55.03 4 Mid slide guide 331 C2110109 2 Screw M12X20
260 GB/T 75 5 Pin Φ5x15 332 C211010608 1 Washer φ12
261 C288012201 1 Square turntable 333 GB/T6173 1 Nut M12X1.25
262 C288TR.01.55.01.01 4 Lower slide guide 334 GB/T5781 12 Screw M6X12
263 C211.TC-421.02A 1 Spindle sleeve for turntable 335 JSM-L-Z6 1 L-union 8-M12
264 C2880147 4 Connecting rod 336 C2110106A 1 Complete bead breaker cylinder
265 C2880124 1 Control plate
266 C2110148 4 Pin for control plate
401 C211011201 1 Bead breaker pedal
402 C211011201 1 Clamping pedal 515 GB/T 70 10 Screw M6×20
SPARE PART LIST
