No. Part code Part Name QTY No. Part code Part Name QTY
IT1 I2110301 Tank 1 IT39 C211016504 T Union 1
IT2 PQ-L10 safety valve 1 IT40 I2330340 Air manometer 1
IT3 I2330341
Hose
(tank to quick exhaust valve) 1 IT41 GB/T5781 Screw M5 6
IT4 I2110312
Hose
(input to quick exhaust valve) 1 IT42
C2110165 Tools box 1
IT5 PT08-01 T-union 1/8" 1 IT43 MOV-03A Exhaust valve 1
IT6 KP-L25 Complete quick exhaust valve 1 IT44 PL08-01 L-Union1/8" 1
IT7 C233030104 Tie-in 1 IT45 Connecting block 1
IT8 I21103011702 Rotating valve casing 1 IT46 PC10-02 Connector 1/4" 8
IT9 I2110313 Hose(Rotating union to slide) 4 IT47 GB/T5781 Screw for fixing air manometer 3
IT10 PC08-01 union 1/8" 3 IT48
Hose
(rotating union to rear flange of clamping cylinder) 2
IT11 I211011701 Rotating union mandrel 1 IT49
Hose
(rotating union to front flange of clamping cylinder) 2
IT12 C211011704 O-ring Φ65x2.65 4 IT50 IT2110117 Complete rotating union 1
IT13 PC12-04 Connector 1/2" 2 IT51 C211033002 Air outlet hose for IT version 1
IT14 I2110314
Hose
(exhaust valve to Rotating union) 2 IT52 Hose 1
IT15 I2110315
Hose
(5-way valve to IT air input) 1 IT53 Front cover 1
IT16 C211011220
Hose
(5-way valve to air input) 1 IT59 P/T-3T-0802 T Union 1
IT17 I2110316 complete 5-way valve 1 IT60
I2110164 Complete IT box 1
IT18 I2110317
Hose
(5-way valve to quick exhaust valve) 1 Pressure regulator
IT19 PC08-01 L-union 1/8" 1 IT101 I2110101 Inflation pedal support 1
IT20 PC-3T-0803 T-union 1 IT102 GB/T 1239.6 Spring 1
IT21 C2110327 Solenoid hose 1 IT103 GB/T 50 Washer φ81
IT22 GB/T41 Nut M6 4 IT104 GB/T 5780 Bolt M8×30 1
IT23 GB/T5781 Screw M6 4 IT105 I2110102 Pedal lever 1
IT24 GB/T5781 Screw M10 2 IT106 I2110103 Inflation pedal 1
IT25 GB/T41 Nut M10 2 IT107 I2110104 Connecting rod 1
IT26 GB/T41 Spring washer 2 IT108 GB/T 5780 Bolt M4×20 1
IT27 GB/T42 gasket 2 IT109 GB/T 50 Washer φ41
IT28 PL12-04 Angle connector 1/2" 2 IT110 GB/T 1337 Self-locking nut M4 1
IT29 I233030303 Tie-in 2 IT111 GB/T 70 Screw M6×20 1
IT30 I233030304 T-Union 1 IT112 GB/T 1337 Self-locking nut M6 1
IT31 I233030301 quick exhaust valve support 1 IT113 GB/T 50 Washer φ61
IT32 I233030305 Union 1 IT114 GB/T 70 Screw M8×25 1
IT33 I233030302 Union 1 IT115 GB/T 68 Screw M8×25 1
IT34 I233030103 Union 1 IT116 GB/T5781 Screw M10X70 4
IT35 I233030105 L-Union 1 IT117 GB/T 1239.6 Spring 1
IT36 I233030106 Nip 2 IT118 GB/T 5780 Bolt M4×20 1
IT37 GB/T5781 Screw M8 3
IT119 GB/T41 Nut M10 1
IT38 C2110167 Tools box support 1 CIP Complete inflation pedal 1
IT Spare Part List
