INSTALLATION INSTRUCTIONS
1. Position the range hood on the center of cooking stove wall. For best
results, the mounting height of the range hood should be 25"-30" above
the top of the range. Mark the position of the holes, which need to be
drilled in order to mount the range hood.
2. According to marks, drill two holes appropriate for heavy duty wall
anchors and screws (not included). Mount the range hood on the wall
with the two screws and anchors and tighten.
3. Install the one-way valve on top of the range hood and assemble the
exhaust pipe and decorative cover.
4. Affix the decorative cover with two M4 tapping screws on the hood body.
5. Make sure all switches are off and then insert the electrical plug into an
outlet.
6. Install indicator diagram
27.5"
Wall Mount:
Drill two holes on the wall, then two
expansions fixed on the wall.
Under Cabinet:
Drill four holes in the ceiling with
four iron expansions fixed.
6
