CABINETS
This range may be installed directly adjacent to existing countertop high
cabinets (36" or 91.5 cm from the floor).For the best look, the cooktop should be
level with the cabinet countertop . This can be accomplished by raising the unit
using the adjustment spindles on the legs.
ATTENTION: the range CANNOT be installed directly adjacent to
kitchen
walls, tall cabinets, tall appliances , or other vertical surfaces above 36"(91.4
cm) high. The minimum side clearance in such cases is 6" (15.2 cm).Wall
cabinets with minimum side clearance must be installed 18" (45.7 cm) above
the countertop with countertop height between 35 1/2" (90.2 cm) and 37 1/2"
(94.6 cm). The maximum depth of wall cabinets above the range shall be 13"
(33.0 cm)
INSTALL GUIDE
14
