Pendular Spreader PDV-PDHV models
25
6.1. LUBRICATION
Before every use and after every 8 hours of effective work, carry out the greasing of the gear box.
It is a good use that the greasing nipples are well cleaned up from mud or
other residuals before using them for inject lubricating grease.
Lubricate with lithium grease the different 5 points, shown in the picture.
One of the grease nipples is located behind the capsule for the closing of the protecting cap of the
lubricating mechanism:
• Take off the capsule for the closing of the distribution mechanism.
• Move the oscillating tube until you can reach the grease nipple from the opening of the
protecting cap.
• Lubricate all the nipples 1 or 2 times.
