Pendular Spreader PDV-PDHV models
35
RIDUTTORE MOD. PDV GEARBOX PDV MODEL
Codice
Code
REF. DESCRIZIONE DESCRIPTION
332.005 1 Forcella (assemblata) Yoke (assembly)
304.110 2 Flangia pendolo (corto o lungo) 03 Flange spout (long or short) 03
600.003 3 Vasca superiore Spreading basin
600.005 4 Asse centrale con vite e rondella Centre axle with screw and washer
301.047 5 Dado speciale flangia Special nut spout
300.061 6 Bullone speciale per cuscinetti Special bolt yoke bearings
300.060 7 Bullone 10,9-M12x65/DM Bolt 10,9-M12x65/DM
300.063 8 Bullone k100-M12x40/DM Bolt k100-M12x40/DM
300.062 9 Bullone k100-M12x50/DM Bolt k100-M12x50/DM
301.048 10 Dado k10/M12/DM Nut k10/M12/DM
321.002 11 Telaio base Mainframe
303.002 12 Rondella 13/rvs Lock washer 13/rvs
310.011 13 Cuscinetto 6206-z Bearing 6206-z
310.013 14 Cuscinetto 6205-2lc Bearing 6205-2lc
310.012 15 Cuscinetto forcella Bearing yoke
306.009 16 Ingrassatore M8x1,25 Grease nipple M8x1,25
303.001 17 Rondella cuscinetto forcella Washer bearing yoke
304.041 18 Tappo cuscinetto inferiore Cap bottom bearing
299.006 19 Guarnizione Seal
299.005 20 Tappo cuscinetto Bearing cap
299.007 21 Guarnizione Seal
