INSTALLATION INSTRUCTIONS
Step 4:
Complete Installation
Install the drip tray inside the bottom rear of the range hood.
Install the baffle filters by inserting at an angle towards the rear of the
range hood. Then push the filter up and insert front of filter into front
recess. Slightly lower and slide back the filter, and make sure the filter is
properly installed in position.
1.
2.
