OPERATING INSTRUCTIONS
COMPATIBLE MODELS: UMC30 / UMC36
RECIRCULATING CHARCOAL FILTERS
Step 3: Twist and lock the filter into place.
Step 4: Repeat Steps 2-3 on the left side of the motor.
Step 5: Reinstall the ARC-FLOW Baffle Filters back into place.
MOTOR
Step 1: Remove the ARC-FLOW Baffle Filters.
Step 2: Locate the motor (pictured below) and align one of the filters with the right side of the motor.
It is recommended that the charcoal filter be replaced every 4-6 months. Charcoal filter replacements
are available for purchase at: www.cosmoappliances.com Charcoal Filter Kit Part# CFK1-TM
Ceiling
Cabinet
Grate (sold separately)
Duct (not included
with ductless models)
Ductless Installation:
Vent duct through cabinet
and attach grate on top of
cabinet (sold separately).
SCAN QR CODE
FOR INSTALLATION
VIDEO
1. Hold Timer Button for 3 Seconds.
Press + Button (D) to set hours.
Press - Button (C) to set minutes.
17
