4-2. Component Names and Functions
No.
Name Functions
1
Change-over
selector switch
Rotate the switch to “MEAS” position to
commence measurement, with the
sampling container removed from the
instrument.
To check the voltage level of the batteries,
rotate the switch to “BATT” position.
2 Sample insert port
Insert port for sampled grease.
The measurement of the steel dust is
conducted when the sampling container is
inserted, while the selector switch is set at
“MEAS” position.
3 LCD display
The display will indicate a digital reading of
the steel dust in the sampled grease.
Also, to indicate the reading of battery
voltage.
4 BATTERY alarm lamp
To indicate the low battery status, when the
battery voltage becomes lower than 3.6V,
the alarm lamp will turn ON.
5 Calibration switch
Calibration switch of the indicated value.
(The instrument is calibrated at factory prior
to shipment. Do not attempt to make any
calibrations.)
6 DC jack
The exclusive jack to accept the plug of the
AC Adapter.
7 Battery compartment
The battery compartment accommodates 4
AA size dry cells.
8 Sampling container
A quantitative sample container to collect
0.8ml of sampling grease.
9 Spatula
A tool used for the collection of sample
grease.
10
AC adapter Exclusive AC adapter. (Option)
