3. Parts
1. On-Off Switch
2. Safety Catch (for on-off switch)
3. Collet Chuck
4. Base Plate
5. Parallel Guide Locking Knob
6. Dust Extractor Port
7. Spindle Lock Button
8. Circular Guide
9. Depth Stop Locking Knob
10. Depth Stop Adjuster
11. Depth Stop
12. Speed Setting
13. Locking Lever
14. Router Depth Fine
Adjustment Screw
15. Carbon Brush Holder
16. Cable Guard
17. Parallel Guide Locking Knob
