Cotech DB7404 - Operation

7
ENGLISH
Chute
1. Make sure thechute’s metal
position lock sits securely in
itscatch.
2. Hold thechute in place and
put on thelock ring.
3. Securethesnap lock on thelock ring.
4. Loosen thewing knobs
on thechute’s hood to set
thedesired discharge angle.
Tightenthewing knobs.
Operation
Oil level checks and refills
Note: The snow blower comes without engine oil. Oilmust be filled before using thesnow blower.
Engineoil capacity is 600 ml.
• Use SAE 5W-30 grade 4-stroke petrol engine oil,
service category SG, SF.
• Unscrew thedipstick and fill up with engine oil so
that thelevel is within therecommended markings on
thedipstick. Donot overfill!
Handy hint: Ask for help to tilt up thesnow blower to
make oil filling easier.
Note: Do not screw thedipstick cap into place when
measuring. Holdit flush against thefilling hole to measure.
IMPORTANT:
The oil should be changed after thefirst 5 hours of use.
