Cotek SK700-112 - Mechanical Drawings

2-3. Mechanical Drawings
REMOTE
PORT
CHASSIS
GROUND
SK700 273.00 [10.75]
SK1000 340.00 [13.39] SK1500 370.00 [14.57]
196.00 [7.72]
SK700 71.50[2.83]
SK1000 88.00[3.46] SK1500 88.00[3.46]
SK700 179.00[7.05]
SK1000 182.00[7.17]
SK1500 191.00[7.52]
SK700 151.00[5 94]
SK1000 154.00 [6.06]
SK1500 163.00[6.42]
S3
S2
PWR.
SAV.
IO
S1
LOAD
LEVEL
INPUT
LEVEL
S4
STATUS
FREQ.
1000W
Pure Sine Wave Power Inverter
POS(+) NEG(-)
DC INPUT
REVERSE POLARITY
WILL DAMAGE UNIT
PURE SINE WAVE INVERTER
AC OUTPUT
ONON
REMOTE
OFF
I
0
8
