HORIZONTAL /
水平安装
17
INSTALLING GRAPHIC CARD
顯卡安裝說明 / 显卡安装说明
The vertical graphic card and the PCI-E riser cable are not
included in the package, please purchase separately.
A
B
Stand-off for VGA riser cable
Motherboard screws and 2.5" SSD screws
A
B
VERTICAL /
垂直安装
主機板螺絲 / 2.5” SSD螺絲
主机板螺丝 / 2.5” SSD螺丝
主機板銅柱 / 垂直顯卡排線銅柱
主机板铜柱 / 垂直显卡排线铜柱
显卡和 PCI-E 转接线不包含在包装内，请单独购买。
顯卡和 PCI-E 轉接線不包含在包裝內，請單獨購買。
16
