Operator’s Manual
17306 CRT Tiller
20 For additional information email info@ardisam.com or call 800-345-6007 M-F 8-5
the engine
engine service center
the engine
- turn engine o and allow muer to cool
- disconnect spark plug wire and secure from spark plug
- remove belt guard
- pull down on drive safety control lever
- manually bend forward belt guide so there is 1/16 inch
or less clearance between belt guide and belt
- replace belt guard and spark plug wire
Tine Axle Shaft of Normal Care section.
FOLLOW ALL SAFETY INSTRUCTIONS
TROUBLESHOOTING
TROUBLESHOOTING GUIDE
While normal care and routine maintenance will extend the
life of your rototiller, prolonged or constant use may eventu-
ally require that service be performed to allow it to continue
operating properly. The troubleshooting guide below lists the
most common problems, causes and remedies.
PROBLEM REMEDY/ACTION
Engine will not start
Engine runs rough, oods during operation
Engine is hard to start
Engine misses or lacks power
Engine will not stop when throttle control is positioned at stop
Tiller moves forward during starting
Tiller is dicult to control when tilling
(machine jumps or lurches forward)
Tines turn, wheels do not turn
Tines turn, wheels turn, tiller does not move
Belts squeal in neutral
Excessive heat build up in transmission/tine area during tilling
WARNING
PRACTICE SAFETY AT ALL TIMES. ENGINE MUST BE
TURNED OFF AND ALLOWED TO COOL, AND SPARK
PLUG WIRE MUST BE DISCONNECTED AND SECURED
BEFORE ATTEMPTING ANY MAINTENANCE OR REPAIR.
FAILURE TO COMPLY WITH THIS SAFETY
REQUIREMENT
CAN RESULT IN SERIOUS PERSONAL INJURY TO YOU
OR BYSTANDERS.
