17306 CRT Tiller
CRT MOTOR MOUNT PARTS LIST
REF.
NO.
PART # DESCRIPTION QT Y.
1 810 BOLT, 5/1624 X 1 HH GR5 2
2 504  4
3 WF516 WASHER, FLAT 5/16” STANDARD ZN 12
4 13453 GUARD, BELT REAR TINE 1
5 53638 RIVET, PLASTIC PUSH IN REAR TINE,
12/05
1
6 1407 SPRING FORWARD ARM 1
7 803 WASHER, 5/16”ID X 11/2”OD FLAT
16 GA.
1
8 48300 BOLT, 5/1618 X 21/4 HHCS GR5 ZN 4
9 31315 BELT, DRIVE L4 POWER RATED 1
10 3178 PULLEY, SINGLE GROOVE ENGINE 1
11 802 BOLT, 5/1624 X 3/4 HH GR5 ZN 2
12 53622 WELDMENT, CABLE PULL PLATE RT,
12/05
1
13 755 SPACER, DRIVE PULLEY .700” 1
14 3364  1
15 1501 BOLT, 5/1618 X 3/4 SFHH GR5 ZN 6
16 53618 CLIP, BELT GUARD TILLERS, 12/05 2
17 8655 BOLT, 5/1618 X 13/4 HH 4
18 17494 TAB, BELT GUARD SUPPORT SMALL
REARTINE
1
19 60G5NY NUT, 5/1618 NYLOC 10
20 48250 BOLT, 1/420 X 13/4 HHCS GR5 ZN 1
21 48261 WASHER, 1/4 FLAT ZINC 5
22 53634 GUIDE BELT REAR TINE 1
23 67538  5
24 48240 BOLT, 1/420 X 11/2 HHCS GR5 ZN 4
25 17491 PAN, LOWER 1
26 17489 PLATE, TRANNY COVER/HOOD
MOUNT
1
27 53413  1
REF.
NO.
PART # DESCRIPTION QT Y.
28 WF38 WASHER, FLAT 3/8 STANDARD ZINC 1
29 48144 BOLT, 3/816 X 2 HHCS GR5 ZN 1
30 53596B  1
31 53617 ARM, FORWARD REAR TINE, 12/05 1
32 1416 PIN CLEVIS 1
33 1408 PULLEY, IDLER FORWARD 1
34 2104  1
35 53637 BUSHING, FORWARD ARM REAR
TINE, 12/05
1
36 739 BELT GUIDE, REVERSE 1
37 1418 PIN COTTER SIZE 2 1
38
*
ENGINE 800 SERIES BRIGGS 1
39 16864 VENT TRANSMISSION 1
* See Briggs and Stratton engine manual for
additional information
